Heavy-Duty Chain Driven Live Roller Conveyors

Chain Driven Live Roller Conveyors

Conveyor Systems & Engineering, Inc. brings you top-tier Chain Driven Live Roller Conveyors designed for the toughest industrial environments. Built for strength and reliability, our conveyors ensure smooth, consistent handling of heavy-duty loads like pallets, drums, and large containers. With rugged construction and precision engineering, they're ideal for warehouses, manufacturing lines, and distribution centers. When performance and durability matter, our CDLR conveyors deliver unmatched value.

What sets us apart is our commitment to customization and quality. Whether you need variable speed options, custom roller spacing, or integration with existing lines, we tailor each solution to fit your exact needs. Backed by expert support and years of industry experience, we help you streamline operations and boost productivity. Trust Conveyor Systems & Engineering, Inc. – where innovative conveyor solutions move your business forward.

Product Features

Heavy-Duty Construction – Built with robust frames and rollers to handle high-capacity loads such as pallets, drums, and industrial components.
Chain Drive System – Provides reliable, positive drive to rollers, ensuring consistent movement even under heavy loads.
Customizable Roller Sizes – Available in various roller diameters and pitches to suit different load types and sizes.
Durable Roller Bearings – Equipped with precision bearings for smooth operation and extended service life.
Supports Bi-Directional Flow – Capable of conveying materials in both forward and reverse directions, enhancing flexibility in layout.
Low Maintenance Design – Minimal moving parts and rugged components reduce downtime and simplify maintenance routines.
Motorized Operation – Driven by electric motors with options for variable speed control to suit different throughput requirements.
Modular Construction – Allows easy expansion, relocation, or integration into existing conveyor systems.
Safety Features – Can be equipped with guards, emergency stop systems, and overload protection for safe operation.
Ideal for Harsh Environments – Suitable for use in manufacturing, warehousing, and distribution environments where durability is essential.

Standard Specifications

Drive Chain	No. 40 roller chain on straight sections.
Bed	Conveying surface width 14", 16", 18", 24", 28", and 34". 3½" x 1½" x 10 gauge powder-painted formed steel channel on one side, 5" x 1½" x 10 gauge formed steel channel on chain drive side. Sections are bolted together with butt couplings and floor supports.
Tread Rollers	2" diameter x 12 gauge steel with #40 sprockets welded to roller tube, 7⁄16" hex shafts. Rollers spaced on 4", 6", 8" and 12" centers. Rollers are roller-to-roller driven.
Chain Guard	Chain guard is mounted to frame to totally enclose drive chain.
Center Drive	Mounted underneath conveyor, near center of section. Can be placed most anywhere in conveyor length. Specify location when ordering.
Floor Supports	Adjustable from 28" to 42" from floor to top of rollers. One support supplied at each end of conveyor and at each bed joint.
Speed Reducer	C-Face mounted heavy-duty worm gear reducer.
Motor	½ HP 230/460V, 3-phase, 60 Hz TEFC motor.
Roller Speed	60 FPM (feet per minute), constant speed.
Capacity	Maximum load: 150 lbs per foot; maximum unit load: 500 lbs. Must not exceed load capacity chart.

Key Applications

Warehousing & Distribution – Efficiently moves heavy pallets and containers throughout the facility.
Heavy Manufacturing – Transports large, bulky components and finished products with reliability.
Drum & Barrel Handling – Specifically designed for the stable conveyance of cylindrical containers.
Accumulation Zones – Provides robust buffering of heavy loads before the next stage of processing or shipping.
Automated Storage & Retrieval (AS/RS) – Seamlessly integrates for automated movement of heavy items in and out of storage.
Harsh Industrial Environments – Withstands demanding conditions, ensuring consistent performance.
Uneven Load Transport – Reliably moves items with irregular bottom surfaces without slippage.
Work-in-Progress Buffering – Facilitates smooth flow and staging of heavy materials within production lines.
Positive Drive Applications – Essential in scenarios requiring consistent speed and preventing load slippage.
Tire & Roll Handling – Effectively conveys challenging circular or rolled goods.
